Viewing posts with category: Instructional videos

Instructional video: How to optimise the BMV-700 series sync parameters

Does your BMV state of charge (SOC) synchronise too early or not detect a full charge?

If so it is worth noting there are various settings for differing batteries and systems, to ensure your BMV works correctly.

The default setup and settings are applicable for most situations, however the instructional video below shows you how to optimise the BMV-700 series synchronisation parameters for varying scenarios, to ensure the battery SOC read-out functions correctly.Continue reading

Instructional video: How to connect the BMV-700 battery monitor

From time to time we hear of people saying they can’t see the loads on their BMV battery monitor – this is down to incorrect wiring. This new instructional video is an aid to ensure the BMV is wired correctly.

BMV-700 series models

There are 3 model variants within the BMV series range: BMV-700 & BMV-702 (6.5- 95 VDC supply voltage range) and the BMV-700HS (60– 385 VDC supply voltage range). The principal function of the BMV series is to follow and indicate the state-of-charge of a battery. The video below gives clear instructions to ensure the BMV-700 and related models are wired correctly.

For the additional functionality that the BMV-702 provides, namely starter battery or temperature or mid-point voltage monitoring, please see the quick install guide.

Continue reading

Instructional video: Upgrade CCGX firmware to v2.00

This excellent instructional video gives clear, straightforward instructions to upgrade to the recently released Color Control GX firmware v2.00 – an upgrade packed with new features and improvements.

Unlike previous updates, v2.00 cannot be installed from the internet. Instead it needs a one time manual upgrade. After this, future updates can be installed automatically via the internet once again.

Instructional videoContinue reading
