Field test: PV Modules

A real world comparison between Mono, Poly, PERC and Dual PV Modules.

Total solar yield: --
S
Total solar yield: --
S
Total solar yield: --
S
Total solar yield: --
S
Total solar yield: --
E
Total solar yield: --
W
Romania
--
--
Installation date: 09-03-2020
--
--
--
--
--
--
--
Irradiance

* This is a field test and the results are specific for this installation on this location please research which is the best solution for your own situation as the results can be different based on environmental influences.

Total solar yield as of 27/03/2023 when the results were reset:
Mono: 9158 kWh
Split-cell: 9511 kWh
Poly: 9113 kWh
Perc: 9471 kWh
Perc-east: 1970 kWh
Perc-west: 1730 kWh

EV Racing

Where fast cars need a fast charge!

Bucharest recently hosted the first eco Grand Prix.
Conducted according to FRAS rules the race – which was open to legitimate licensed road vehicles – witnessed sixteen drivers taking part in the two-day Slalom event. Each driver completed four laps of a 1000 metre course – two test runs, and two competition runs.
The coned-marked slalom course was laid out with twists and turns to be navigated by two classes of vehicle: up to 250HP; and those above 250HP. Only one vehicle was permitted to occupy the track at any time in order to achieve maximum speed grab!
With just half a second separating the top three competitors the winners were:
  1. Ciprian Cherciu in a Tesla Model 3
  2. Mihai Beldie in a modified Porsche 944
  3. Dragoș Craiovan in a modified Mini
Car modification was permitted – but all vehicles had Electric Propulsion – none were hybrids.
Represented on the field were:
  • Tesla Model 3
  • a modified Porsche 944
  • a modified Mini
  • Tesla S85
  • Peugeot E208
  • Dacia Logan

Victron Energy achieved not one but TWO two glamorous milestones at the event – not only did our sponsored vehicle win; but we showcased our prototype Mobile Electric Vehicle Charging Station …without which the event could scarcely have gone ahead!

The eco Grand Prix heralds a new era of sustainable Grand Prix racing. As such, having a recharge station with a generator banging away in the background doesn’t quite fit the bill – so a prototype solar powered recharge station with Lithium battery storage was designed by Eastern European sales manager Lucian Popescu, and built by the well-known and successful distributors Darcomenergy and EcoAlternativ.

It featured an hydraulically operated solar panel array allowing the 12 x 370W panel arrays to be dropped for easy transport – and opened allowing the panels to be optimally-tilted toward the sun when in use. Two SmartSolar MPPT 250/60 units harvest energy for storage in 4 Lithium 25.6V Smart batteries. Three-Phase recharge with a 22kW power capability was supplied by 3 Quattro 10000 Inverter Chargers.

Also essential to the build was:

Back at the pit between races, the recharge station was the main attraction!
Let’s take a look at some of the highlights from the event in this video shot by Ciprian Cherciu from Eco Drive:
